Description
SRV2KL-IN Features
Overview | |
| Lead time | Usually in Stock |
General | |
| provided equipment | Documentation CD |
| Basic UPS signalling RS-232 cable | |
| CD with software | |
| Country-specific detachable power cord | |
| Rack mounting brackets | |
| Stabilization/wall mounting feet | |
| User manual | |
| USB cable | |
Physical | |
| cable length | 1.50 m |
| number of rack unit | 2U |
| colour | Black |
| depth | 46.2 cm |
| height | 8.8 cm |
| net weight | 18.2 kg |
| width | 43.8 cm |
Input | |
| network frequency | 40…70 Hz |
| plug standard | India 3-pin 16A |
| input voltage limits | 110…285 V adjustable (half load) |
| inputvolt_other | 220 V |
| 240 V | |
| switching current capacity | 13 A |
| input voltage | 230 V |
Output | |
| rated power in W | 1600 W |
| Maximum configurable power in W | 1600 W |
| output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| outputvolt_other | 220 V |
| 240 V | |
| crest factor | 3:01 |
| UPS type | Double conversion online |
| Wave type | Sine wave |
| nb of power socket outlets | 4 India 2/3-pin 6A |
| bypass type | Internal bypass (automatic and manual) |
| output voltage | 230 V |
Conformance | |
| product certifications | BIS |
Environmental | |
| ambient air temperature for operation | 0…40 °C |
| relative humidity | 0…95 % non-condensing |
| operating altitude | 0…10000 ft |
| ambient air temperature for storage | -20…60 °C |
| storage altitude | 0.00…15240.00 m |
| acoustic level | 50 dBA |
| IP degree of protection | IP20 |
Batteries & Runtime | |
| battery type | Lead-acid battery |
| number of battery free slots | 0 |
| Battery recharge time | 4 h |
| additional information | Configurable for 220 : 230 or 240 nominal output voltage |
| liquid value | 0 |
| battery voltage | 48 V |
Communications & Management | |
| control panel | Multifunction LCD status and control console |
| alarm | Audible and visible alarms prioritized by severity |
Surge Protection and Filtering | |
| Surge energy rate | 600 J |
Packing Units | |
| Package 1 Weight | 21 kg |
| Package 1 Height | 21.8 cm |
| Package 1 width | 55 cm |
| Package 1 Length | 70 cm |
Contractual warranty | |
| Warranty | 2 years repair or replace |
