Description
BX600C-IN Key Features
| Main | |
acoustic level | 45 dBA |
battery curve | B |
battery type | Lead-acid battery |
product certifications | BIS |
curve equation | Efficiency |
curve load maximum | 100 % |
curve X-axis maximum | 100 % |
curve X-axis minimum | 0 % |
curve X-axis title | Load |
curve X-axis units | Percentage |
curve Y-axis maximum | 100 % |
curve Y-axis minimum | 50 % |
curve Y-axis title | Efficiency |
curve Y-axis units | Percentage |
extended runtime | 0 |
Maximum configurable power in VA | 600 VA |
Maximum configurable power in W | 360 W |
liquid value | 0 |
mounting mode | Not rack-mountable |
mounting preference | No preference |
number of battery filled slots | 0 |
number of battery free slots | 0 |
Battery recharge time | 6 h |
cable length | 1.22 m |
depth | 23.7 cm |
height | 21.8 cm |
number of cables | 1 |
Number of power module filled slots | 0 |
Number of power module free slots | 0 |
net weight | 4.7 kg |
rated power in VA | 600 VA |
rated power in W | 360 W |
Surge energy rate | 255 J |
width | 10.7 cm |
operating altitude | 0…10000 ft |
ambient air temperature for operation | 0…40 °C |
ambient air temperature for storage | -15…45 °C |
storage altitude | 0.00…15240.00 m |
UPS size | WS |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
graph display | 0 |
redundant | No |
runtime at 100W | 0:17:00 |
runtime at 200W | 0:03:50 |
runtime at 300W | 0:01:00 |
runtime at 50W | 0:40:00 |
show note OP temperature | No |
two post mountable | 0 |
No | |
full load runtime | 00:00:01 360 W |
half load runtime | 00:04:36 180 W |
input voltage | 230 V |
input voltage limits | 145…290 V |
battery charger power | 14 W rated |
nb of power socket outlets | 3 India 2/3-pin 6A |
network frequency | 47…63 Hz |
output voltage | 230 V |
provided equipment | User manual |
Warranty card | |
relative humidity | 0…95 % |
Battery power in VAH | 86 VAh runtime |
| Input | |
plug standard | India 3-pin 6A |
| Output | |
output frequency | 47…63 Hz sync to mains |
| Communications & Management | |
control panel | LED status display with on line : on battery : replace battery and building wiring fault |
alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Packing Units | |
Package 1 Weight | 5.2 kg |
Package 1 Height | 29.5 cm |
Package 1 width | 16.5 cm |
Package 1 Length | 31 cm |
| Offer Sustainability | |
Sustainable offer status | Green Premium product |
REACh free of SVHC | Yes |
EU RoHS Directive | Compliant |
EU RoHS Declaration | |
Mercury free | Yes |
RoHS exemption information | Yes |
| Contractual Warranty | |
Warranty | 2 years repair or replace |
