Description
BR1000G-IN Key Features
Main | |
acoustic level | 45 dBA |
battery curve | B |
battery type | Lead-acid battery |
product certifications | BIS |
curve equation | Efficiency |
curve load maximum | 100 % |
curve X-axis maximum | 100 % |
curve X-axis minimum | 0 % |
curve X-axis title | Load |
curve X-axis units | Percentage |
curve Y-axis maximum | 100 % |
curve Y-axis minimum | 50 % |
curve Y-axis title | Efficiency |
curve Y-axis units | Percentage |
extended runtime | 1 |
Maximum configurable power in VA | 1000 VA |
Maximum configurable power in W | 600 W |
Let through voltage rating | 330 V |
liquid value | 0 |
mounting mode | Not rack-mountable |
mounting preference | No preference |
number of battery filled slots | 0 |
number of battery free slots | 0 |
Battery recharge time | 7.4 h |
number of battery replacement quantity | 1 |
cable length | 1.52 m |
depth | 38.2 cm |
height | 30.1 cm |
number of cables | 1 |
performance multiplier | 1 |
Number of power module filled slots | 0 |
Number of power module free slots | 0 |
net weight | 11.35 kg |
rated power in VA | 1000 VA |
rated power in W | 600 W |
Surge energy rate | 680 J |
Number of tare power | 54 W |
width | 11.4 cm |
operating altitude | 0…10000 ft |
ambient air temperature for operation | 0…40 °C |
battery life | 2…4 year(s) |
ambient air temperature for storage | -15…45 °C |
storage altitude | 0.00…15240.00 m |
Transfer time | 8 ms typical : 12 ms maximum |
UPS size | WS |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
graph display | 1 |
redundant | No |
show note OP temperature | No |
two post mountable | 0 |
No | |
colour | Black |
input voltage | 230 V |
input voltage limits | 150…280 V |
battery charger power | 29 W rated |
efficiency | 84 % (full load) |
80 % (half load) | |
nb of power socket outlets | 4 India 3-pin 6A |
2 India 3-pin 6A surge | |
network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
output voltage | 230 V |
provided equipment | Telephone cable |
User manual | |
USB cable | |
Warranty card | |
relative humidity | 0…95 % |
battery option | BR24BPG-IN 1 432 VAh |
Battery power in VAH | 216 VAh runtime |
value multiplier | 1 |
Input | |
plug standard | India 3-pin 6A |
Output | |
output frequency | 50/60 Hz +/- 1 Hz sync to mains |
Communications & Management | |
control panel | Multifunction LCD status and control console |
alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Packing Units | |
Package 1 Weight | 12.77 kg |
Package 1 Height | 38.1 cm |
Package 1 width | 22.9 cm |
Package 1 Length | 48.3 cm |
SCC14 | 2.07313E+13 |
Number of Units in Package 2 | 2 |
Package 2 Weight | 27.14 kg |
Package 2 Height | 381.00 mm |
Package 2 width | 508.00 mm |
Package 2 Length | 508.00 mm |
Offer Sustainability | |
Sustainable offer status | Green Premium product |
REACh free of SVHC | Yes |
EU RoHS Directive | Compliant |
EU RoHS Declaration | |
Mercury free | Yes |
RoHS exemption information | Yes |
Contractual warranty | |
Warranty | 2 years repair or replace |
