Description
BVX1600LI-IN Unique Features
Main | |
Lead time | Usually in Stock |
input voltage | 230 V |
output voltage | 230 V |
Output voltage | 230 V |
rated power in W | 900 W |
rated power in VA | 1600 VA |
nb of power socket outlets | 5 India 2/3-pin 6A |
cable length | 1.22 m |
number of cables | 1 |
battery type | Lead-acid battery |
provided equipment | User manual |
General | |
Number of power module free slots | 0 |
Number of power module filled slots | 0 |
redundant | No |
UPS size | WS |
Physical | |
colour | Black |
height | 19.0 cm |
width | 14.0 cm |
depth | 39.0 cm |
net weight | 10.2 kg |
mounting preference | No preference |
mounting mode | Not rack-mountable |
two post mountable | 0 |
USB compatible | No |
Input | |
network frequency | 40…70 Hz +/- 5 Hz auto-sensing |
plug standard | India 3-pin 16A |
input voltage limits | 140…300 V |
input protection type | Circuit breaker |
Output | |
Maximum configurable power in W | 900 W |
output frequency | 50/60 Hz +/- 1 Hz unsynchronised |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
graph display | 1 |
Maximum configurable power in VA | 1600 VA |
Transfer time | 6 ms typical : 10 ms maximum |
Conformance | |
product certifications | BIS |
Environmental | |
ambient air temperature for operation | 0…40 °C |
relative humidity | 0…95 % non-condensing |
operating altitude | 0…3000 m |
ambient air temperature for storage | -20…50 °C |
storage Relative Humidity | Non-condensing 0…95 % |
storage altitude | 0…15000 m |
acoustic level | 40 dBA |
IP degree of protection | IP20 |
Batteries & Runtime | |
number of battery filled slots | 0 |
number of battery free slots | 0 |
Battery recharge time | 6 h |
battery voltage | 24 V |
battery capacity | 7 Ah |
extended runtime | 0 |
Communications & Management | |
control panel | LED status display with on line : on battery : replace battery and overload indicators |
alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge Protection and Filtering | |
Surge energy rate | 255 J |
Packing Units | |
Package 1 Weight | 11.2 kg |
Package 1 Height | 29.7 cm |
Package 1 width | 23.5 cm |
Package 1 Length | 49.5 cm |
Contractual warranty | |
Warranty | 2 Years on UPS & 1 Year on Battery |
