Main

acoustic level

58 dBA

battery curve

B

battery type

External battery system

bypass type

Built-in static bypass

crest factor

3:01

curve equation

Efficiency

curve load maximum

100 %

curve X-axis maximum

100 %

curve X-axis minimum

0 %

curve X-axis title

Load

curve X-axis units

Percentage

curve Y-axis maximum

100 %

curve Y-axis minimum

50 %

curve Y-axis title

Efficiency

curve Y-axis units

Percentage

Emergency power off

Yes

extended runtime

0

Maximum configurable power in VA

10000 VA

Maximum configurable power in W

9000 W

liquid value

0

load power factor

0.5 leading to 0.5 lagging

mounting mode

Not rack-mountable

mounting preference

No preference

number of battery filled slots

0

number of battery free slots

0

Battery recharge time

5 h

cos phi

0.98

depth

70.6 cm

free slots

1

height

43.3 cm

Number of power module filled slots

0

Number of power module free slots

0

net weight

27.5 kg

rated power in VA

10000 VA

rated power in W

9000 W

Number of tare power

525 W

width

13.4 cm

operating altitude

0…10000 ft

output harmonic distortion

< 2% for 0 to 100% linear load and < 5% for full non-linear load

output overload operation

60 seconds at 125% and 30 seconds at 150%

output voltage tolerance

+/- 1% static and +/- 5% at 100% load step

ambient air temperature for operation

0…40 °C

ambient air temperature for storage

-10…60 °C

storage altitude

0.00…15240.00 m

UPS size

S

UPS type

Double conversion online

Wave type

Sine wave

graph display

1

redundant

No

show note OP temperature

No

two post mountable

0

No

number of input connectors

1 hard wire 3-wire (1P + N + E)

1 hard wire 5-wire (3P + N + E)

input voltage

230 V

input voltage limits

100…280 V adjustable

160…285 V

IP degree of protection

IP20

efficiency

94.4 % (full load)

94.5 % (half load)

network frequency

40…70 Hz auto-sensing

output connector type

Hard wire 3-wire (H N + E) 1

output voltage

230 V

provided equipment

Basic UPS signalling RS-232 cable

Dust filter

User manual

Warranty card

relative humidity

0…95 % non-condensing

battery option

SRC192XLBP-IN 1 1958 VAh

SRC192XLBP-IN 2 3916 VAh

SRC192XLBP-IN 3 5874 VAh

SRC192XLBP-IN 4 7832 VAh

Battery power in VAH

0 VAh runtime

input current

81 A (1 phase)

28 A per phase (3 phases)

outputvolt_other

220 V

240 V

harmonic distortion

Less than 2 %

Output

output frequency

47…53 Hz for 50 Hz nominal sync to mains

50 Hz +/- 0.1 % for 50 Hz nominal unsynchronised

60 Hz +/- 0.1 % for 60 Hz nominal unsynchronised

50/60 Hz +/- 1 Hz sync to mains

50/60 Hz +/- 3 Hz sync to mains

Packing Units

Package 1 Weight

32 kg

Package 1 Height

57 cm

Package 1 width

27.5 cm

Package 1 Length

79 cm

Offer Sustainability

EU RoHS Directive

Compliant

EU RoHS Declaration

Mercury free

Yes

RoHS exemption information

Yes

Contractual warranty

Warranty

2 years repair or replace
